Environmental keying: 16-byte key derived from uptime

This article is 100% defensive and academic. Code examples are neutralized for analysis and detection, they do not show or execute payloads. The goal is to explain the technique, show weaknesses and offer actionable heuristics to hunt and prevent this family of attacks.

Quick summary

Some threat actors use “environmental keying”: they derive a runtime key from system properties (time, uptime, PID, MAC address, etc.). Here we focus on a specific pattern: a 16-byte (128-bit) key derived from system uptime, combined with pieces (split) embedded in the binary (head + tail). The mechanism gives the attacker resistance against simple static extraction, but it produces detectable signals in static and dynamic analysis.

Below I describe:

• implementation variants (3 practical schemes),
• neutralized reconstruction code (read/derive only),
• weaknesses and defensive attack vectors (window brute-force, overlay analysis),
• heuristic rules (YARA/PCRE) and instrumentation ideas to hunt.

---

Threat model and motivation

Attacker motivation:

• Do not store the key in clear in the binary (increases stealth).
• Make the key depend on the environment (avoid detection by simple static comparisons).
• Allow the operator who controls the binary (or knows the scheme) to reconstruct the key without the full key stored.

Problems for the defender:

• The key is not in clear text, it is dispersed and depends on a predictable quantity uptime.
• The attacker can “split” metadata to reduce static surface area.

Defender benefit:

• uptime is predictable; with appropriate heuristics it is possible to recover the key (or brute-force within a plausible window).
• Operationally the pattern generates consistent telemetry (self-reads, time syscalls and hashing, XOR loops) — very useful for behavioral detection.

---

How the attacker commonly implements it (simplified pattern)

1. At runtime the program obtains uptime (e.g. clock_gettime(CLOCK_MONOTONIC) or mach_absolute_time() on macOS).

2. It computes K = SHA256(some_material || uptime_bytes || other_material)[:16].

   • some_material / other_material may include embedded seeds, MAC, PID or pieces stored in the binary (split).
3. Uses K to encrypt/decrypt via XOR or a lightweight stream cipher.
4. To allow the operator to know K later, they place seed in two locations in the binary (for example: 8 bytes at the start and 8 bytes at the end), or use another split scheme that can be recomposed at runtime.

Note: using uptime as the only source of entropy makes the scheme vulnerable to window brute-force; mixing additional sources increases entropy but also increases the number of reads/syscalls that can be detected.

---

Three practical schemes (conceptual)

Scheme A: seed_hi + seed_lo XOR with uptime → hash

• Binary stores seed_hi (8 bytes) at the beginning and seed_lo (8 bytes) at the end.

• Runtime:

  • u = uptime_ns (8 bytes)
  • buf = (seed_hi XOR u) || (seed_lo XOR u) → hash = SHA256(buf) → K = hash[:16]
• Tradeoff: simple, but if u is predictable it suffices to test time windows.

Scheme B: store half the key and recompute the other half

• Binary stores K_partA (8 bytes) at the start, computes K_partB = SHA256(u || nonce)[:8] at runtime.
• K = K_partA || K_partB
• Tradeoff: reduces workload for an attacker who already has K_partA; defender can brute-force u to recover K_partB.

Scheme C: K = SHA256(seed || uptime || nonce)[:16]

• Binary stores seed and nonce in distinct places; combines with uptime.
• More robust if seed and nonce are secret; still vulnerable if uptime is the only unknown entropy.

All schemes can be used with byte-by-byte XOR or as a 128-bit key for block XOR (neutralized: we do not provide payload encryption implementations here; only reconstruction / hunting techniques).

---

Neutralized code: reconstructing the key from head+tail + uptime (C)

Warning: this code only shows how to reconstruct the key (useful for analysts). It does not perform or show payload encryption. On macOS reading the current binary requires different methods (see notes below).

// This code implements Scheme A. For Schemes B and C,
// the logic that builds the 'buf' buffer and the hash
// calculation should be adjusted according to the article.

#include <stdio.h>
#include <stdint.h>
#include <string.h>
#include <time.h>
#include <openssl/sha.h>
#include <unistd.h>
#include <fcntl.h>
#include <sys/stat.h>

int main(int argc, char **argv) {
    const char *path = "sample_binary.bin";
    int fd = open(path, O_RDONLY);
    if (fd < 0) { perror("open"); return 1; }

    unsigned char head[8], tail[8];
    if (pread(fd, head, 8, 0) != 8) { perror("pread head"); close(fd); return 1; }

    struct stat st;
    if (fstat(fd, &st) != 0) { perror("stat"); close(fd); return 1; }
    off_t sz = st.st_size;
    if (sz < 16) { fprintf(stderr, "file too small\n"); close(fd); return 1; }

    if (pread(fd, tail, 8, sz - 8) != 8) { perror("pread tail"); close(fd); return 1; }
    close(fd);

    struct timespec ts;
    clock_gettime(CLOCK_MONOTONIC, &ts);
    uint64_t uptime_ns = (uint64_t)ts.tv_sec * 1000000000ULL + ts.tv_nsec;

    unsigned char buf[16];
    for (int i = 0; i < 8; ++i) {
        buf[i] = head[i] ^ ((uptime_ns >> (i*8)) & 0xFF);
        buf[8+i] = tail[i] ^ ((uptime_ns >> ( (i%8)*8)) & 0xFF);
    }

    unsigned char digest[SHA256_DIGEST_LENGTH];
    SHA256(buf, sizeof(buf), digest);

    unsigned char key[16];
    memcpy(key, digest, 16);

    printf("derived key: ");
    for (int i=0;i<16;i++) printf("%02x", key[i]);
    printf("\n");
    return 0;
}

macOS specific notes

• /proc/self/exe does not exist. To read the current executable use _NSGetExecutablePath, proc_pidpath (libproc) or paths passed to the analyst.
• mach_absolute_time() is often used instead of clock_gettime on macOS; adapt uptime reading according to platform.

---

How an analyst can recover the key when uptime was not stored

• Window brute-force: if the author did not store the exact instant, the analyst can test a plausible window of uptimes (for example ±N minutes around the likely execution time). Each attempt produces a candidate key — validate it against some confirmation (embedded checksum, known header or try to decode a small portion that should be plausible).
• Constraints: higher resolution (nanos vs seconds) increases search space; if the author used nanos the search can be impractical without extra hints. However, many authors use second or minute granularity to make the technique practical for them; this is a weakness.

Operational tip: combine brute-force with plausibility heuristics (decoded ASCII strings, magic bytes PNG/ELF/Mach-O) to reduce defender cost.

---

Detectable signals — practical heuristics

Static

• Overlay / appended data: executables with extra data at the end (tail) or with high-entropy content right at the beginning (head). Entropy-by-window scripts commonly detect this.
• Metadata pieces at start/end: constant byte sequences of 8–32 bytes in unusual regions.
• Strings related to hashing: presence of SHA256, SHA1, OpenSSL (statically linked) in combination with file read operations.

Dynamic / behavioral

• Typical sequence: open(self) → pread(head) → pread(tail) → clock_gettime / mach_absolute_time → SHA256 → XOR/decoding loop → action (file write, network). Monitor and correlate by process and within short time windows.
• Self-binary reads with small offsets (0 and EOF-8) followed by hashing library calls.
• Network connections soon after decoding (e.g., upload of payload or beacon).

---

Countermeasures and mitigation

For operators and response teams:

• Block arbitrary uploads/execution on hosts (WAF/mod_security policies for pages serving HTA/JS malicious content).
• Check artifacts for overlays (size vs expected image) during forensic intake.
• Use EDR/telemetry to identify pattern: read-self + hash + xor + network.
• Triage: prioritize samples with appended data and time + hashing calls.

For defensive architectures:

• Prevent unprivileged processes from reading sensitive areas unnecessarily.
• Enable detection of unusual self-binary reads on critical hosts.

---

Variations and hardenings the attacker may apply

• Add PID/MAC/hostname to the hash input → increases entropy, but adds detectable activities (interface reads, syscalls).
• Rounding/quantization of uptime (e.g. uptime in minutes) → reduces operator precision but makes brute-force easier.
• Obfuscation of the reads (use trampolines, wrappers, syscall indirections) → slows analysts, but telemetry correlation remains possible.

In short: hardenings make the technique more costly for both attacker and analyst; from a defensive perspective, telemetry correlation is the most robust path.

---

Practical YARA and PCRE examples

Use these as a starting point; tune for your environment and evaluate false positives.

PCRE:

/(pread|fread|read).{0,200}(CLOCK_MONOTONIC|mach_absolute_time|clock_gettime).{0,400}(SHA256|CC_SHA256|SHA1)/is

YARA concept:

rule possible_uptime_keying_generic {
  meta:
    author = "you"
    desc = "heuristic: head/tail seeds + hashing usage"
  strings:
    $s1 = "SHA256" ascii nocase
    $s2 = "mach_absolute_time" ascii
    $s3 = "clock_gettime" ascii
    $bytecodeOSX = { 31 ?? e8 ?? ?? ??} // example of generic bytecode based on behavior
    $bytecodeOSLinux = { 27 48 ?? e8 ?? ?? ??} // example of generic bytecode based on behavior
  condition:
    filesize > 64KB and
    (
      $s1 and
      ($s3 or $s3) and
      ($bytecodeOSX or $bytecodeOSLinux)
    )
}

---

Quick checklist for analysts

1. Check if a binary has appended data (tail) / high-entropy head.
2. Prove: extract 8–16 bytes from head and tail and try combinations with coarse uptime (seconds/minutes).
3. If you recover a candidate key, attempt to decode an initial block (first KB) and look for plausible ASCII / magic bytes.
4. Correlate with telemetry: self-binary read, time syscall, hashing, write/transfer activity.
5. If confirmed, generate IOCs (hashes, strings, offsets) and create tuned YARA/PCRE rules.

---

Conclusion

Deriving keys from uptime with splits in the binary is an elegant obfuscation trick: it removes the explicit key from the binary and requires runtime recomposition. In practice this trick tends to fail against defenses equipped with:

• instrumentation able to correlate reads and hashing,
• static scanning for overlays and high entropy,
• and, when necessary, defender brute-force within plausible windows.
